Vertical Type Air Handling Unit

Application

Vertical air cooling units are applicable for ventilation and refrigeration and are widely used in factories, supermarkets, restaurants and malls.

Product parameters of Vertical Air Cooling Unit
Model Dimension(mm) Weight(Kg)
A B C D E G H K L 4-row 6-row
20 700 850 1200 1050 640 230 260 790 450 145 152
30 700 950 1200 1050 640 300 260 890 500 155 162
40 700 1050 1450 1300 640 330 290 990 600 175 185
50 800 1050 1600 1450 740 310 340 990 700 210 223
60 800 1050 1600 1450 740 400 340 990 800 239 251
70 800 1200 1800 1650 740 370 400 1140 850 260 276
80 800 1350 1800 1650 740 370 400 1290 850 277 296
90 950 1350 2050 1900 890 430 480 1290 1000 325 345
105 950 1550 2050 1900 890 430 480 1490 1000 360 375
120 950 1700 2050 1900 890 560 480 1640 1000 372 395
135 950 1950 2050 1900 890 1040 400 1890 1000 490 525
150 950 1950 2100 1940 890 1040 400 1890 1050 512 537
180 950 2150 2300 2140 890 1200 480 2090 1150 605 621
210 950 2350 2300 2140 890 1200 480 2290 1200 646 683
240 950 2650 2300 2140 890 1570 480 2590 1200 690 741
270 950 2650 2500 2340 890 1570 480 2590 1300 743 792
300 950 2650 2500 2340 890 1570 480 2590 1450 795 850
330 1150 2900 2700 2540 1090 1590 570 2840 1450 967 1035
350 1150 3000 2700 2540 1090 1780 640 2940 1450 1032 1107
400 1150 3000 2950 2790 1090 1780 640 2940 1700 1070 1195
450 1150 3000 3100 2940 1090 1780 640 2940 1850 1115 1130
500 1150 3500 3300 3140 1090 1780 640 3440 1950 1203 1450
Product feature

1. Adoption of a lightweight aluminum alloy frame makes it convenient for onsite dismounting and maintenance.
2. Internal and external double layer polyurethane color steel panels avoids the formation of a cold bridge on the shell while operating.
3. Duplex air inflow centrifugal machine: air cooling units are tried and tested by dynamic and static equilibrium tests before delivery.
4. Closed rolling bearings function as the automatic adjusting center of gravity, automatic locking and anti-pushing. Pre-filling of lube oil makes it unnecessary for maintenance in normal conditions.
5. The filter is a plate type that can be cleaned and reused.
